Engineering Design and Review for SUBSTATION physical, schematic, and wiring packages.
- Design drawing review for engineering accuracy
- Provider of review services prior to 30%, 60%, 90%, and IFC design issue
- Verify wiring and ground connections for CT circuits and AC schematics
- DC schematic review of relay, control switch, and lockout applications
- Physical design review of conductor, bus, conduit, and grounding connections
- Bill of Material review for quantity and completion
- Calculation review of AC station service and DC loads
- Manufacturer print check
Pi Engineering reanalyzes design packages as large as 600 pages. PiE will markup drawings using Adobe Pro or Bluebeam for utility team drafting and provide drafting services as requested. Expect thorough, complete, and timely work.
This is a small business company, employee-owned and operated. PE Licensed in Ohio, Indiana, and Colorado.
